Product Name: | Heat Treatment Muffle Furnace | Application: | Metal Heat Treatment |
---|---|---|---|
Max Temperature: | 1000 Degree | Furnace Type: | Box Furnace |
Fuel: | Electricity | Heating Element: | Resistance Wire |
Voltage: | 220V | Warranty: | 1 Year |
Ater Sale Service: | Online Technical Support | ||
High Light: | Heat Treatment Muffle Furnace,Muffle Furnace 1000 Degree,Muffle Furnace Box Type |
Metal Heat Treatment Muffle Furnace 1000 Degree Box Type
The Muffle Furnace is made of high-quality ceramic fiber blocks according to the corresponding formula, and the resistance wire and the furnace are integrated by vacuum filtration, and then made by drying, engraving, polishing and other processes.
Parameter
Model | Chamber size | Voltage(V) | Power(KW) | Max temperature(C) | Heating element | Furnace structure |
SX2-2.5-10 | 80*120*200 | 220 | 2.5 | 1000 | resisitance wire | one/split |
SX2-4-10 | 120*200*300 | 220 | 4 | 1000 | resisitance wire | one/split |
SX2-8-10 | 160*250*400 | 380 | 8 | 1000 | resisitance wire | one/split |
SX2-30-13 | 400*400*600 | 380 | 30 | 1350 | silion carbide rod | one/split |
SX2-45-13 | 600*600*600 | 380 | 45 | 1350 | silion carbide rod | one/split |
SX2-65-13 | 700*700*800 | 380 | 65 | 1350 | silicon carbide rod | one/split |
SX2-8-16 | 120*150*300 | 380 | 8 | 1600 | silicon molybdenum rod | one/split |
SX2-12-16 | 160*200*400 | 380 | 12 | 1600 | silicon molybdenum rod | one/split |
SX2-17-16 | 200*300*500 | 380 | 17 | 1600 | silicon molybdenum rod | one/split |
