Product Details:
Payment & Shipping Terms:
|
| Max Temperature: | 1800 Degree | Voltage: | 380V 50Hz 3phase |
|---|---|---|---|
| Power: | 35kw | Application: | Metal Melting |
| Size: | 460*270*450mm | Material: | Steel |
| Cooling Way: | Water Cooled | Core Selling Point: | Easy To Operate |
| High Light: | 1800C Aluminum Melting Furnace,Aluminum Melting Furnace Light Weight,35kw Small Electric Melting Furnace |
||
The Characteristics of medium frequency induction melting furnace:
1. Small size
2. Light weight
3. Fast in fusion
4. Simple operation
5. Easy to assemble and move
6. Ready to run when power supply, inductor and input and output lines are connected
7. Less energy consumption with less than 0.3 Kw/h for an average per melting of 1 kg of gold
8. With overcurrent, overvoltage, undervoltage, lack of water, overheating and other protection functions
9. Applied for roughing gold and other uses
Technical Parameters of IGBT Medium Frequency Induction Melting Furnace:
| Melting furnace model | Steel and stainless steel | Gold, copper,silver | aluminum |
| 30kw | 2kg | 10kg | 3kg |
| 40kw | 5kg | 20kg | 6kg |
| 50kw | 10kg | 30kg | 10kg |
| 60kw | 18kg | 50kg | 20kg |
| 80kw | 25kg | 100kg | 30kg |
| 120kw | 50kg | 150kg | 50kg |
| 160kw | 100kg | 250kg | 100kg |
We Guarantee:
1. Standard wooden case packaging.
2. Foam and plastic are used for shockproof and waterproof.
Steel belt and rivets are used to fasten the wooden case.
3. The bottom pallet can bear 3 times weight than goods.
4. Delivery time: 7-25 working days
